The Mining Truck air tank factory direct of Xiamen Jiedeng Machinery adopts a classic cylindrical structure, with uniform force distribution and no stress concentration, effectively preventing the tank from cracking and leaking.
The manufacturing process is solid, resistant to vibration deformation, and can stably store high-pressure gas sources, ensuring the sensitive and reliable braking of commercial vehicles.
It is equipped with a drainage valve, which can discharge water, gasoline, oil, and other contaminants, as well as prevent corrosion and clogging.
It is available in both aluminum and iron styles, balancing lightweight corrosion resistance and high cost-effectiveness, and is suitable for various harsh working conditions of mining trucks.
Commercial vehicle air storage tanks generally adopt a cylindrical design. High-pressure gas can be evenly distributed on the cylinder wall to withstand the force, avoiding the stress concentration problem at the corners of the square tank body, thereby reducing the risks of cracking and leakage from the root cause.
The cylindrical structure saves materials, has a lighter weight, has mature and stable welding technology, and can also be installed in the narrow space of the chassis, with stronger resistance to vehicle jolts and deformation. The mining air storage cylinder also adopts the cylindrical design, and thanks to its excellent pressure-bearing characteristics, it is suitable for harsh industrial and mining high-pressure conditions.
1. To meet the demand for instantaneous gas supply: For truck pneumatic braking, a stable high-pressure gas source
is required immediately. The air compressor cannot keep up with the peak demand for braking gas, so a storage
cylinder is necessary to assist in gas supply.
2. Coordinated pressure stabilization and energy storage: The air compressor and tank for truck work together. They
store compressed air in advance to balance the fluctuations in pipeline pressure.
3. Purify the gas source: The storage cylinder can filter out moisture and impurities in the compressed air,
ensuring that the braking response is sensitive and the braking force is stable.
4. Ensure driving safety: Reduce gas line failure problems, avoid the risk of braking failure, and comprehensively
guarantee the driving safety of commercial vehicles.
1. The air source is prone to accumulating impurities and water: During the compression process of air, water vapor
condenses and oil contaminants are mixed in, which tend to accumulate at the bottom of the air reservoir.
2. It can easily cause safety hazards: The accumulated water will corrode the cylinder wall, rust the brake
pipelines and valve body. In winter, freezing will also block the air path, causing brake failure.
3. Practical function of the drain valve: It can regularly remove water and oil contaminants, purify the internal
air source, and effectively extend the service life of air path components.
4. Industry standard configuration: Mainstream universal air tanks for trucks are all equipped with a drain valve,
and it is an indispensable and important component of the air brake system.
In the aftermarket truck air tanks market, the two types of air tanks have significant differences in their positioning.
The iron model focuses on affordability and practicality, while the aluminum model emphasizes lightweight design, corrosion resistance, and high-quality requirements.
| Item | iron air tank | aluminum air tank |
| Weight | The weight of the same specification is relatively high. | It can be reduced by more than 30%, and the lightweight advantage is remarkable. |
| Cost & Price | Low raw material and processing costs, reasonable prices | The cost of aluminum materials and processing is high, and the market price is even higher. |
| Antiseptic Property | It is prone to rust and corrosion, so it needs to be protected with spray painting and electroscopic coating. | It has inherent anti-corrosion properties and is not prone to rusting, making it durable. |
| Application | General freight transportation, regular commercial vehicles, emphasizing high cost-effectiveness | High-end commercial vehicles and mining vehicles, focusing on weight reduction, energy saving and long-term durability |
